DENSO - 5306 - Iridium Spark Plug - IW20
The DENSO 5306 Spark Plug for Street. Six times harder than platinum, iridium withstands temperatures up to 4,000°F Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves 360° laser welding of electrode provides a seal that resists wear even in the worst conditions A reliable, quality-built component from a brand riders trust. Sold individually.
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
- Ground Electrode Shape: Grooved
- Riding Style: Street
- Type: Resistor
- Electrode Tip Material: Iridium
- Ground Electrode Shape: Taper Cut
- Heat Range: 20
- Units: Each
- Electrical Resistance: 5k Ohms
- Product Name: Spark Plug
- Thread Reach: 19.1 mm
- Terminal Configuration: Threaded Stud
- Center Electrode Projection: Non-Projected
- Center Electrode Type: Fine Wire
- Hex Size: 20.6 mm
- Spark Gap: 0.043"
- Spark Gap: 1.1 mm
- Model: IW20
- Style: Iridium
