WISECO - VT2797 - Piston Kit with Gaskets - Standard - Twin Cam 88”/96”/103” Bored to 1746 cc (106 Cubic Inch)
Engine rebuilds are only as good as the parts that go back in, and when it comes to the piston — the component under more sustained thermal and mechanical stress than anything else in the top end — there is no room for compromise. The WISECO VT2797 is a precision-engineered piston kit with gaskets for Standard / Twin Cam 88”/96”/103” Bored to 1746 cc (106 Cubic Inch) engines, built to hold dimensional tolerances across thousands of heat cycles. Forged from high-silicon aluminum alloy for maximum strength and dependability, giving you the kind of fit-from-day-one accuracy that prevents premature wear on the cylinder wall, wrist pin, and rings. Twin Cam pistons have Armor Plating which improves ring seal, eliminates ring micro-welding and improves the piston's ability to defend against detonation damage. Displacement: 1746 cc. Whether you are overboring for more displacement or simply replacing what age and hours have worn out, the VT2797 gives you a forged foundation you can trust.
Features
- Forged from high-silicon aluminum alloy for maximum strength and dependability
- Twin Cam pistons have Armor Plating which improves ring seal, eliminates ring micro-welding and improves the piston's ability to defend against detonation damage
- Kit includes pistons, retainer clips, chrome piston pins, top end gasket kit, and VM-Rings package (1.2 mm steel, positive twist, gas nitrided top ring, 1.2 mm cast iron, taper under-hook scraper ring and 2.0 mm three piece, flex vent oil ring with steel chrome-faced rails); VMF- Ring package includes 3.0 mm oil ring instead of 2.0 mm oil ring
- Pistons are made in the USA
- Wiseco pistons that use VM-rings can only be fitted with Wiseco VM-rings.
Specifications
- Displacement : 1746 cc
- Piston Material : 2618 Aluminum Alloy
- Riding Style : Street
- Bore Size : 3.937"
- Type : Top End
- Color/Finish : Aluminum
- Bore - Oversize : Standard
- Product Name : Rebuild Kit
- Engine Type : 4-Stroke
- Piston Diameter : 3.934"
- Skirt Coating : ArmorGlide®
- Compression Ratio : 10.0:1
- Units : Kit
<div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> For '99-'17 Twin Cam 88"/96"/103" bored to 1746 cc (106 cubic inch) with 4-3/8" stroke crank (except twin cooled models).</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> 103" kits require cylinder boring.</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> Kit Includes:</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> • 2x Pistons</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> • 2x Ring Set</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> • 2x Wrist Pins</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> • 4x Circlips</div><div style="border:1px solid #1a6fb0;padding:8px 12px;margin:8px 0;background:#f0f7ff;border-radius:4px;"><strong style="color:#1a6fb0;">ⓘ NOTE:</strong> • Top-End Gasket Kit</div>
