WISECO - K2806 - Piston Kit - 4.135” Bore - 121 CI - 114”/117” M8
A piston that fits loose burns oil and loses compression. One that fits tight seizes under heat. The WISECO K2806 is built for your 4.135” Bore / 121 CI / 114”/117” M8 engine with the kind of precise dimensional control that sits exactly where it should — delivering clean combustion sealing and smooth cylinder wall contact from the first fire-up. Features ArmorX™ piston coating for superior protection in extreme conditions and reduced wear. ArmorFit™ skirt coating auto-adjusts to the cylinder wall so there’s no need to measure clearance; provides smooth, quiet, trouble-free operation. Compression Ratio: 11.3:1. Every serious rebuild deserves components engineered to this standard, and the K2806 delivers it.
Features
- Features ArmorX™ piston coating for superior protection in extreme conditions and reduced wear
- ArmorFit™ skirt coating auto-adjusts to the cylinder wall so there’s no need to measure clearance; provides smooth, quiet, trouble-free operation
- Dome design for improved flame travel to maximize air/ fuel burn efficiency
- High compression (11:1) for added power
- Superfinish piston pin reduces friction and improves scuff resistance
- Enhanced pin oiling for improved lubrication and reduced friction
- Augmented ring land details improve ring seal and function
- Dedicated rings for precise fit, improved compression and oil control
- Kit includes two pistons, rings, piston pins and circlips
- Made in the USA
- Fits OEM and Screamin’ Eagle cylinder heads.
Specifications
- Compression Ratio: 11.3:1
- Piston Material: Forged 2618 Aluminum
- Skirt Coating: ArmorFit™
- Bore Size: 4.135"
- Piston Diameter: 4.132"
- Product Name: Piston Kit
- Riding Style: Street
- Displacement: 121 CI
- Units: Kit
- Model: Black Edition™
- Stroke Length: 4.500"
