S&S CYCLE - 330-0339 - Camshaft - Easy Start - 635 H.O. Gear Drive - Twin Cam '07-'17 | Dyna '06
Whether restoring a machine to factory spec or building something better, the S&S CYCLE 330-0339 gives you a camshaft kit that meets the demands of serious street use. Allows for easy start by initially reducing crank compression, but once the engine starts and rpm increases, the compression release lobe is centrifugally retracted and the engine runs normally, with full compression, and without any loss in performance. High lift camshaft for modified engines with 106” or greater displacement and compression ratios between 10.0:1 and 11.0:1, giving you a level of quality that holds up across the full service life of the component. Best power from 3000 rpm - 6000 rpm. Includes camshafts, 4-gear set, gearcover gasket, bearings, retaining ring, o-ring, threat lock and instructions. Not for models with OEM compression releases.. The 330-0339 is the kind of component that earns its place in any build or repair by doing exactly what it is supposed to, every time. Sold as a complete kit.
Features
- Allows for easy start by initially reducing crank compression, but once the engine starts and rpm increases, the compression release lobe is centrifugally retracted and the engine runs normally, with full compression, and without any loss in performance
- High lift camshaft for modified engines with 106” or greater displacement and compression ratios between 10.0:1 and 11.0:1
- Best power from 3000 rpm - 6000 rpm
- Includes camshafts, 4-gear set, gearcover gasket, bearings, retaining ring, o-ring, threat lock and instructions
- Made in the USA
- Not bolt-in.
- Not for models with OEM compression releases.
- Works well with stock, un-ported heads, but S&S CNC ported heads are recommended.
- High-lift valve springs, adjustable pushrods, and clearance checks are required.
- Due to the inherent characterics of gear drives, there may be more valve train noise.
Specs
- Exhaust Lift at TDC: 0.284”
- Application: Intake
- Exhaust Lobe Centerline: 100.5°
- Exhaust Lift: 0.635”
- Intake Close: 43.5°
- Intake Duration: 243°
- Riding Style: Street
- Type: Gear
- Exhaust Close: 37.5°
- Application: Exhaust
- Intake Lift at TDC: 0.115”
- Product Name: Camshaft Kit
- Intake Lift: 0.635”
- Units: Kit
- Exhaust Duration: 276°
- Exhaust Open: 58.5°
- Intake Lobe Centerline: 102°
- Intake Open: 19.5°
- Grind: 635 H.O.
- Model: Easy Start
