FEULING PARTS - 1019 - Cam - 594 Series - Conversion Chain Drive - Twin Cam '99-'06 (except '06 Dyna)
The DRAG SPECIALTIES 1019 is the chain that pulls strong, stays clean, and keeps delivering. This chain conversion chain covers a wide range of motorcycle applications with consistent power transfer. Smaller high-revving displacement style engines in lighter bikes looking to twist the throttle and tap into some horsepower (2500-6800 RPM). Large displacements respond well to increased compression ratio and smaller displacements will require it. 594 cams require high-performance valve springs, pushrods, lifters, carburetor or throttle body work, performance exhaust, intake and clutch. Sold as a pair.
Features
- Fierce performing camshaft for an array of engine sizes, large displacement 103", 110" and 124" engines looking for a superior torque band with excellent horsepower gains in heavy bikes (2200-6250 rpm)
- Smaller high-revving displacement 95" style engines in lighter bikes looking to twist the throttle and tap into some horsepower (2500-6800 RPM)
- Large displacements respond well to increased compression ratio and smaller displacements will require it
- 594 cams require high-performance valve springs, pushrods, lifters, carburetor or throttle body work, performance exhaust, intake and clutch
- Made in the USA
Specs
- Type: Chain Conversion
- Application: Intake
- Intake Lift: 0.594"
- Intake Lobe Centerline: 108.5°
- Exhaust Duration: 260°
- Grind: 594 Series
- Exhaust Lift: 0.604"
- Intake Lift at TDC: 0.190"
- Model: Reaper
- Riding Style: Street
- Units: Pair
- Exhaust Lobe Centerline: 114°
- Intake Open: 19°
- Product Name: Camshaft
- Application: Exhaust
- Exhaust Close: 16°
- Exhaust Lift at TDC: 0.167"
- Exhaust Open: 64°
- Intake Close: 56°
- Intake Duration: 255°
