COMETIC - C8658 - Head Gasket - 84 mm - Suzuki
The COMETIC C8658 is an MLS (Multi-Layer Steel) head gasket sized for the 84 mm bore on 1999-2015 Suzuki Hayabusa models (1396 cc displacement), using Load Control Embossments for even torque load and better piston ring seal while minimizing bore distortion, with embossed outer layers coated in Viton for durability across harsh sealing environments — no dowel pins, made in the USA.
Features
- Quality materials developed for maximum performance tolerances and longevity
- MLS (Mutli-Layer Steel) head gaskets promote an even torque load across the gasket sealing surface utilizing LCE (Load Control Embossments), providing less bore distortion and better piston ring seal for more power
- Single-Layer Steel (SLS) gaskets feature a stainless steel core and embossed outer surfaces that create a heavy-duty seal between the center steel layer and the gasket mating surfaces
- Center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements
- Outer layers are embossed and coated on both sides with Viton to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes
- Made in the USA
Specs
- Features: with No Dowel Pins
- Material: MLS (Multi-layer Steel)
- Product Name: Gasket
- Riding Style: Street
- Displacement: 1396 cc
- Thickness: 0.030"
- Units: Each
- Bore Size: 84.00 mm
- Thickness: 0.76 mm
- Type: Cylinder Head
